Bell Housing Type Extruder

Name: Bell Housing Type Extruder
Brand: DECCAN DYNAMICS
Price: 3000000 INR
Availability: InStock

Price 3000000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Bell Housing Type Extruder Specification

Drive Type
Electric Motor Driven

Working Temperature
Up to 300C

Cooling System
Air/Water Cooling

Speed
Variable, up to 60 rpm

Automation Grade
Semi-Automatic

Machine Type
Bell Housing Type Extruder

Control System
PLC Based Control Panel

Power Supply
Three Phase (380V/440V, 50/60 Hz)

Weight
Approx. 1800 kg

Features
Robust construction, precise temperature control, easy operation

Noise Level
Below 75 dB

Production Capacity
100 500 kg/hr

Size
Standard/Customizable

Material
High-grade Alloy Steel

Dimension (L*W*H)
3200 mm x 1100 mm x 1500 mm

Usage & Applications
Plastic extrusion, cable covering, profile production

Safety System
Emergency Stop, Overload Protection

Barrel Heating
Ceramic Band Heaters

Surface Finish
Powder Coated

Maximum Torque
2500 Nm

Color
As per requirement

Screw L/D Ratio
28:1

Output Type
Continuous

Screw Diameter
65 mm

Hopper Capacity
60 Liters

Bell Housing Type Extruder Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
1 Unit Per Month

Delivery Time
1 Months

Main Domestic Market
North India

About Bell Housing Type Extruder

As a renowned company, we are engaged in offering a superior quality range of Extruder-Bell Housing Type. The offered housing is precisely engineered in adherence with set industry norms using the finest quality components and ultra-modern technology. This housing is used in various engineering industries. Also, we make certain that offered housing is checked on various quality parameters to ensure their fine finish. Our valuable clients can avail this product from us at industry leading price.

Extruder Bell Housing TypeSpecification :-

Plant capacity	1	3	5	8
Power	5hp	7.5 hp	15 hp+10 hp+1 hp	25 hp + 20 hp.+1 hp
Flux Cylinder Bore	Dia 103 mm	Dia 115 mm	Dia 150 mm	Dia 225 mm
Flux Cylinder length	450mm	675 mm	800 mm	950 mm
Max. Ram Pressure	200 kg/cm2	200 kg/cm2	200 kg/cm2	200 kg/cm2
Oil Cylinder Capacity	60 tons	62 Tons.	150 Tons	275 Tons.
Hydraulic Cylinder Bore	200 mm	232 mm	317.5 mm	420 mm
No. of Flux Cylinder	1 No	1 No	1 No	1 No
Oil Cylinder Stroke	650 mm	900 mm	1000 mm	1050 mm
Specific Pressure	754 kg/cm2	813 kg/cm2	896 kg/cm2	700 kg/cm2
Flux Cylinder Capacity	3.75 litre	7.0 litre	14 litre	37.75 litre
Flux Discharge	2500 cc/min	3300 cc/min	3600 cc/min	7500 cc/min.

Housing Type Extruder Bell Features :-

Easy to fit
Robust construction
Dimensional accuracy
Precise design

Robust Performance and Construction

This extruder boasts a sturdy build with high-grade alloy steel, ensuring long-lasting durability and operational stability. The robust construction is complemented by a powder-coated surface finish, which protects against corrosion and wear in demanding industrial environments.

Advanced Heating and Cooling Systems

Ceramic band heaters provide precise barrel temperature control up to 300C, essential for optimal plastic processing. The integrated air and water cooling systems efficiently maintain desired process conditions, preventing overheating and ensuring consistent output quality.

User-Centric Design and Safety

Engineered for easy operation, the extruder incorporates a PLC-based control panel for precise adjustments. Emergency stop and overload protection features safeguard both operators and equipment, promoting a safe and reliable manufacturing workspace.

FAQs of Bell Housing Type Extruder:

Q: How does the ceramic band heating system improve extrusion performance?

A: The ceramic band heating system provides uniform and precise barrel temperature up to 300C, improving melt quality and process stability, which leads to consistent product output in plastic extrusion and profile production.

Q: What types of material can be processed with this extruder?

A: This machine is ideal for processing various plastic polymers commonly used in extrusion, cable covering, and profile manufacturing, thanks to its robust screw design and advanced temperature control capabilities.

Q: When is the emergency stop and overload protection engaged?

A: The emergency stop can be activated manually at any time to instantly halt the machine for safety, while the overload protection system automatically functions when excessive operational loads are detected, preventing damage to the equipment.

Q: Where is this Bell Housing Type Extruder typically installed?

A: It is suitable for installation in industrial environments such as plastic extrusion factories, cable manufacturing units, and profile production lines, and is available throughout India for export, supply, and manufacturing needs.

Q: What is the process for setting variable speed and production rates?

A: Variable speed control is managed through the PLC-based panel, enabling operators to adjust screw speed up to 60 rpm. This fine-tuning permits production rates between 100 and 500 kg/hr based on application requirements.

Q: How does the semi-automatic operation benefit users?

A: The semi-automatic operation simplifies the extrusion process, reducing manual intervention while ensuring accurate control and flexibility. This design increases productivity and lowers the risk of human error, making it user-friendly for diverse industrial teams.

Q: What are the key benefits of powder-coated surface finish?

A: Powder coating ensures enhanced resistance to corrosion, abrasion, and chemicals, extending the longevity of the extruder even in challenging production environments.
